| Place of Origin: | china |
| Brand Name: | kangrui |
| Certification: | 900 |
| Model Number: | 2015-88 |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | us3-200 |
| Packaging Details: | Details: Each tube is sleeved in plastic bag individually, will be put into carton box and wooden ca |
| Delivery Time: | 3-15 |
| Payment Terms: | T/T |
| Supply Ability: | 50000000 |
Product Feature
There is no damage to hose body caused by welding heat, adopting mechanical clinching assembly, the structure is tight and with reasonable craft, it has low cost and long life compare with welding type. The unique simple connection to the pipeline make it the best choice for piping work, especially for low, high temperature and high frequency vibration ambient.
Drawing
Specifications
| Nominal Diameter | Spec. | PN(Mpa) | Length(mm) | ||
| DN15 | DQ-W50 | 1.6 | Above and include 250 | ||
| DN20 | DQ-W50 | 1.6 | Above and include 250 | ||
| DN25 | DQ-W50 | 1.6 | Above and include 250 | ||
| DN32 | DQ-W50 | 1.6 | Above and include 250 | ||
| DN40 | DQ-W50 | 1.6 | Above and include 250 | ||
| DN50 | DQ-W50 | 1.6 | Above and include 250 | ||
